DEVIreg™ Hot Water

DEVIreg™ Hotwater is an electronic programmable controller with 4 channels for on DIN rail mounting. Every channel can be set Individually to maintain hot water with the option to disinfect manually, or on a schedule. The channels sensors can be selected between 7 different temperature sensors including NTC 15 kOhm at 25°C. Building Management System (BMS) control is possible through the Modbus RS485 serial interface. DEVIreg™ Hotwater has been developed to give the user easy setup, control of their hot water system, along with the option to disinfect. The controller allows up to 4 channels to be operated, each capable of controlling a separate pipe system. 2 sensors have to be used to measure the temperature for each channel.

DEVIreg™ Hot Water

Benefits

  • 4 independent channels
  • 2 control modes:
  • Hot water maintenance
  • Hot water maintenance with disinfection
  • user definable accuracy
  • Compatible with 7 sensors types
  • Sensor failure monitoring
  • Accurate temperature control
  • Alarm functions
  • Multilanguage menu
  • Graphic LCD display
  • BMS control

Specification

Nominal voltage

110/230 V AC, 50–60 Hz

Power consumption, max.

20 V A

Relay load:
Resistive (inductive, cos(phi sign) = 0,6)
Total current load limit
C1-NO1, C2-NO2
C3-NO3-NC3, C4-NO4-NC4
C8-NO8-NC8

32 A
10 (3,5) A (100 000 cycles)
6 (4) A (100 000 cycles)
6 (4) A (100 000 cycles)

Sensor inputs

Analog inputs AI1-AI8

Compatible sensors

NTC15k (15 kOhm @ 25 °C) (standard)
NTC10k (10 kOhm @ 25 °C)
NTC5k (5 kOhm @ 25 °C)
NTC2k (2 kOhm @ 25 °C)
NTC100 (100 kOhm @ 25 °C)
NTC16k (16,7 kOhm @ 100 °C)
PT1000 (1000 Ohm @ 0 °C)

Digital inputs

DI1-DI8, voltage free contacts, on/off inputs

Connection specification

Grouped screws plug-in connectors

Cable specification for connectors termi- nals

0,2-2,5 mm2

Battery back-up time, min.

48 hours

Ball pressure test

125 °C

Pollution degree

2 (domestic use)

Controller type

1 C

Operating temperatures and conditions

CE: -20T60 / UL: 0T55, 90% RH non-condensing

Storage temperature and conditions

-30Т85, 90% RH non-condensing

IP class

IP40 only on the front cover

Protection class

Class II -

Immunity against voltage surges

Over Voltage Category II

Dimensions (H/W/D), DIN dimension :

110(122) х 138 х 70 mm, 8 DIN modules

Mounting method

DIN rail, complying with EN 60715

Weight, net

511 g

Menu languages:

GB,DE,BG,CZ,DK,ES,EE,FI,FR,HR,HU,LT,LV, NL,NO,PL,PT,RO,RU,SE,SR,SI,SK,TR,UA,CN.

Base controller

Danfoss MCX08M2\

Software class

A

Warranty scope

20 years

Compliance

Standard compliance: • IEC60800:2009

Compliance

Product variants

Choose a product variant to go for product page on Danfoss Store, where you can find more details and documents

Table

You can drag the table horizontally with your cursor to access further columns.

Item no

Product name

Type

140F1133

DEVIregTM Hotwater

Programmable controller with 2 Wire sensor NTC 15 kOhm at
25 °C, 3 m
