DEVIcomfort™ 10T
Electric Underfloor Heating Cable for Floor Renovation Projects
DEVIcomfort™ 10T is a fully screened twin-conductor electric heating cable designed for indoor floor heating applications. The cable features a 360° screen and a red PVC outer sheath (non-UV stable). Its round cable profile and low build height support installation in renovation and new-build floor heating projects.
The heating cable is intended for use with a compatible thermostat. Proper temperature control helps maintain the desired floor temperature and can support efficient system operation, depending on building conditions, thermostat settings and user behaviour.
The cold lead is supplied as an installation cable with solid conductors to support installation. The visible cable connection helps installers identify the transition point between the heating cable and cold lead during installation.
Each cable undergoes quality-control testing, including electrical resistance testing, high-voltage testing and material inspections as part of the manufacturing process.
DEVIcomfort™ 10T is covered by the DEVIwarranty™ programme according to the applicable warranty terms and conditions.
The product also has an Environmental Product Declaration (EPD), providing quantified information about the product's environmental impacts across relevant life-cycle stages.
Benefits
- Fully screened twin-conductor heating cable
- 360° cable screen
- Round cable profile
- Low installation height
- Red PVC outer sheath (non-UV stable)
- Installation cable with solid conductors
- Visible cable connection point
- Quality-control tested during production
- EPD available
- Compatible with thermostat-controlled electric floor heating systems
Specification
|
Nominal voltage |
230 V~ |
|
Construction |
Round, twin conductor with 100% screen, one cold lead |
|
Output |
10 W/m @ 230 V~ |
|
Max. permissible use temperature, On / Off |
85 °C / 90 °C |
|
Cable thickness |
4 mm |
|
Deformation strength |
600N |
|
Pulling strength |
120N |
|
Conductor insulation |
FEP |
|
Outer sheath |
Lead free PVC |
|
Screen |
Alu-foil; 0,5 mm2 tinned copper drain wire |
|
Cold lead |
4 m DTWB, 2 x 1,0 mm2, with screen |
|
Min. installation temperature |
-5 °C |
|
Bending Ø, min. |
5 cm |
|
IP Class |
IPX7 |
|
Set with double adhesive tape |
Double adhesive tape 25 mm x 50 m |
|
Set with Flexpipe |
Flexpipe, inner ø6,7 mm, outer ø10 mm, 2,5 m, Black |
Warranty scope
Compliance
Standard compliance: • IEC60800:2009
GARAN Label
| Item no. | Cable length [m] | Heating output [W] | Cable resistance [Ohm] | Cold lead conductor quantity | Cable output [W/m] | Supply voltage [V] AC | Cold lead length [m] | Cold lead size [mm²] |
|---|---|---|---|---|---|---|---|---|
| 87101700 | 10.000 m | 100 W | 529.0000 Ohm | 2 | 10 W/m | 230 V | 4.0 m | 1.0 mm² |
| 87101702 | 20.000 m | 200 W | 264.0000 Ohm | 2 | 10 W/m | 230 V | 4.0 m | 1.0 mm² |
| 87101706 | 29.000 m | 290 W | 183.3000 Ohm | 2 | 10 W/m | 230 V | 4.0 m | 1.0 mm² |
| 87101708 | 41.000 m | 410 W | 129.7000 Ohm | 2 | 10 W/m | 230 V | 4.0 m | 1.0 mm² |
| 87101710 | 50.000 m | 500 W | 105.8000 Ohm | 2 | 10 W/m | 230 V | 4.0 m | 1.0 mm² |
| 87101712 | 58.000 m | 580 W | 90.9000 Ohm | 2 | 10 W/m | 230 V | 4.0 m | 1.0 mm² |
| 87101714 | 70.000 m | 695 W | 76.3000 Ohm | 2 | 10 W/m | 230 V | 4.0 m | 1.0 mm² |
| 87101716 | 81.000 m | 810 W | 65.2000 Ohm | 2 | 10 W/m | 230 V | 4.0 m | 1.0 mm² |
| 87101718 | 90.000 m | 900 W | 58.8000 Ohm | 2 | 10 W/m | 230 V | 4.0 m | 1.0 mm² |
| 87101720 | 99.000 m | 990 W | 53.3000 Ohm | 2 | 10 W/m | 230 V | 4.0 m | 1.0 mm² |
| 87101722 | 128.000 m | 1280 W | 41.4000 Ohm | 2 | 10 W/m | 230 V | 4.0 m | 1.0 mm² |
| 87101724 | 142.000 m | 1420 W | 37.3000 Ohm | 2 | 10 W/m | 230 V | 4.0 m | 1.0 mm² |
| 87101728 | 170.000 m | 1710 W | 30.9000 Ohm | 2 | 10 W/m | 230 V | 4.0 m | 1.0 mm² |
| 87101100 | 10.000 m | 100 W | 529.0000 Ohm | 2 | 10 W/m | 230 V | 4.0 m | 1.0 mm² |
| 87101102 | 20.000 m | 200 W | 264.0000 Ohm | 2 | 10 W/m | 230 V | 4.0 m | 1.0 mm² |
| 87101104 | 29.000 m | 290 W | 183.3000 Ohm | 2 | 10 W/m | 230 V | 4.0 m | 1.0 mm² |
| 87101106 | 41.000 m | 410 W | 129.7000 Ohm | 2 | 10 W/m | 230 V | 4.0 m | 1.0 mm² |
| 87101108 | 50.000 m | 500 W | 105.8000 Ohm | 2 | 10 W/m | 230 V | 4.0 m | 1.0 mm² |
| 87101110 | 58.000 m | 580 W | 90.9000 Ohm | 2 | 10 W/m | 230 V | 4.0 m | 1.0 mm² |
| 87101112 | 70.000 m | 695 W | 76.3000 Ohm | 2 | 10 W/m | 230 V | 4.0 m | 1.0 mm² |
| 87101114 | 81.000 m | 810 W | 65.2000 Ohm | 2 | 10 W/m | 230 V | 4.0 m | 1.0 mm² |
| 87101116 | 90.000 m | 900 W | 58.8000 Ohm | 2 | 10 W/m | 230 V | 4.0 m | 1.0 mm² |
| 87101118 | 99.000 m | 990 W | 53.3000 Ohm | 2 | 10 W/m | 230 V | 4.0 m | 1.0 mm² |
| 87101120 | 128.000 m | 1280 W | 41.4000 Ohm | 2 | 10 W/m | 230 V | 4.0 m | 1.0 mm² |
| 87101122 | 142.000 m | 1420 W | 37.3000 Ohm | 2 | 10 W/m | 230 V | 4.0 m | 1.0 mm² |
| 87101124 | 170.000 m | 1710 W | 30.9000 Ohm | 2 | 10 W/m | 230 V | 4.0 m | 1.0 mm² |
| 140F0800 | 10.000 m | 100 W | 529.0000 Ohm | 2 | 10 W/m | 230 V | 4.0 m | 1.0 mm² |
| 140F0801 | 20.000 m | 200 W | 264.0000 Ohm | 2 | 10 W/m | 230 V | 4.0 m | 1.0 mm² |
| 140F0802 | 29.000 m | 290 W | 183.3000 Ohm | 2 | 10 W/m | 230 V | 4.0 m | 1.0 mm² |
| 140F0803 | 41.000 m | 410 W | 129.7000 Ohm | 2 | 10 W/m | 230 V | 4.0 m | 1.0 mm² |
| 140F0804 | 50.000 m | 500 W | 105.8000 Ohm | 2 | 10 W/m | 230 V | 4.0 m | 1.0 mm² |
| 140F0805 | 58.000 m | 580 W | 90.9000 Ohm | 2 | 10 W/m | 230 V | 4.0 m | 1.0 mm² |
| 140F0806 | 70.000 m | 695 W | 76.3000 Ohm | 2 | 10 W/m | 230 V | 4.0 m | 1.0 mm² |
| 140F0807 | 81.000 m | 810 W | 65.2000 Ohm | 2 | 10 W/m | 230 V | 4.0 m | 1.0 mm² |
| 140F0808 | 90.000 m | 900 W | 58.8000 Ohm | 2 | 10 W/m | 230 V | 4.0 m | 1.0 mm² |
| 140F0809 | 99.000 m | 990 W | 53.3000 Ohm | 2 | 10 W/m | 230 V | 4.0 m | 1.0 mm² |
| 140F0810 | 128.000 m | 1280 W | 41.4000 Ohm | 2 | 10 W/m | 230 V | 4.0 m | 1.0 mm² |
| 140F0811 | 142.000 m | 1420 W | 37.3000 Ohm | 2 | 10 W/m | 230 V | 4.0 m | 1.0 mm² |
| 140F0812 | 170.000 m | 1710 W | 30.9000 Ohm | 2 | 10 W/m | 230 V | 4.0 m | 1.0 mm² |
